Recycle Waste Paper Pulp Small Egg Tray Making Machine Forming Egg Tray Machine Price

Recycle Waste Paper Pulp Small Egg Tray Making Machine Forming Egg Tray Machine Price

automatic egg tray making machine

small egg tray making machine

2000pcs/h Egg Tray Making Machine

Place of Origin:

Jinan, Shandong, China

Brand Name:

Wanyou

Certification:

CE

Model Number:

ZSJ-2000

Contact Us
Request A Quote
Product Details
Processing Type:
Pulp Molding Machine
Voltage:
220-440V
Product Keywords:
Egg Tray Machine
Raw Material:
Waste Paper
Output For Egg Tray:
2000pcs/h
Warranty:
2 Years
Payment & Shipping Terms
Minimum Order Quantity
1
Price
USD 8000-11000
Packaging Details
in container
Delivery Time
35 working days
Payment Terms
Western Union, MoneyGram, L/C, T/T
Supply Ability
1 set per month
Product Description

Small Recycle Waste Paper Pulp Forming Egg Tray Making Machine



Description of Egg Tray Machine:

Paper Egg Tray Making Machine / Pulp Molding Machine / Germany Valves uses waste paper as raw material to produce the egg trays for chicken farm factory or other customer who needs the trays. It has 2 types forming method: one is Reciprocating Type, the other is Rotary Type Egg Tray Making Machine. It can make many simple shape and large quantity demand egg trays, apple trays, egg cartons, egg boxes, wine trays, shoe trays, etc..using waste paper as raw material.

Technical data of Large Capacity Rotary forming TypeEgg Tray Machine:

Egg Tray Mold Quantity 12pcs(3pcs*4) 16pcs(4pcs*4) 24pcs(3pcs*8) 32pcs(4pcs*8)
Raw material Waste paper Waste paper Waste paper Waste paper
Egg tray Capacity(pcs/hour) 2000 2500 3000 4000
Net weight per piece (gram) 70-75 70-75 70-75 70-75
Waste paper consumption 150kg/ h 150kg/h 188kg/h 225kg / hour
Water Consumption 0.45ton / h 0.6ton/h 0.68ton/h 0.9ton / h
Natural Gas Consumption of Dryer 75cbm/h 90cbm/h 110cbm/h 120cbm/h
Boiler model (natural gas fuel Kcal) 800*103 1000*103 1200*103 1500*103
Worker requirement 5-7workers 5-7workers 8-10workers 8-10workers
Power Requirement Without dryer 70KW 80KW 100KW 100KW
With dryer 100KW 120KW 130KW 150KW
Area of workshop Without dryer More than
200 M²
More than 200 M² More than 250 M² More than 250 M²
With dryer More than 400M²
Dryer18M
More than 400M²
Dryer20M
More than 520M² dryer30M More than 520M²
Dryer32M
Container Requirement Without dryer 40ft*1 40ft*1 40ft*1 40ft*1
With dryer 40ft*4 40ft*4 40ft*5 40ft*5
Remarks:
1. The Capacity calculated base on 30-packed egg tray(size 300x300mm, weight 70g~75g).
2. Workshop size is for reference only and could be adjusted according to actual size of client's plant.
3. The above specification is for reference only, due to continuous technology development, data will be updated from time to time.
4. Pulp Molding Equipment are non-standard equipment, we are able to provide customized solution according to specific requirements from customer.
5. Welcome to contact us anytime, our professional team will provide more effective help and supports for you.
Egg Tray Mold Quantity 12pcs(3pcs*4 faces)
Raw material Waste paper
Egg tray Capacity 2000pcs/hour
Net weight per piece (gram) 70g-75g
Waste paper consumption 135kg / hour
Water Consumption 0.5ton / hour
Natural Gas Consumption of Dryer 60cbm/h
Worker requirement 5-7workers
Machine Length 8m-38m
Machine weight 8-32tons
Power Requirement Without dryer 70KW
Area of workshop Without dryer More than 200 M²
Container Requirement Without dryer 40ft*1
Remarks: 1. The egg tray Capacity calculated base on 30-packed egg tray(size 300x300mm, weight 70g~75g). 2. Workshop size is for reference only and could be adjusted according to actual size of client’s plant.

Egg tray(30-egg) Egg box/egg carton(6-egg, 10-egg, 12-egg, 6+6-egg, 15-egg, 18-egg and etc)This production line is suitable for the following products:

Fruit tray (for apple,tomato, pear and etc) Cup carrier(4 pack and 2 pack) Seeding tray and bottle trays.

Some medical-care products and fixed shape(the design doesn’t change frequently) pulp molding products with large quantity.

Egg tray machine features:

1. controlled by computer, no needs infrastructure construction.

2. Egg tray forming molds easy changed, and it’s very easy to change any moulds to the machine.

3. England technology, and spare parts is very famous brand from Germany, Taiwan…

4. with 2 years warranty.

5. The installation of the whole line is easy.

Recycle Waste Paper Pulp Small Egg Tray Making Machine Forming Egg Tray Machine Price 0

Recycle Waste Paper Pulp Small Egg Tray Making Machine Forming Egg Tray Machine Price 1Recycle Waste Paper Pulp Small Egg Tray Making Machine Forming Egg Tray Machine Price 2Recycle Waste Paper Pulp Small Egg Tray Making Machine Forming Egg Tray Machine Price 3Recycle Waste Paper Pulp Small Egg Tray Making Machine Forming Egg Tray Machine Price 4

Drying system can be choose:
(1) Natural drying method: The product is dried directly by weather and natural wind.
(2) Traditional drying: brick tunnel kiln, heat source can choose natural gas, diesel, coal, dry wood,A heat source such as liquefied petroleum gas.

Recycle Waste Paper Pulp Small Egg Tray Making Machine Forming Egg Tray Machine Price 5
(3) New multi-layer drying line: 4-layer metal drying line can save more than 30% energy compared to transmission drying. The main heat source is clean energy such as natural gas, diesel oil, liquefied petroleum gas and methanol.

Recycle Waste Paper Pulp Small Egg Tray Making Machine Forming Egg Tray Machine Price 6
