Egg Tray / Apple Tray / Egg Carton Making Machine 350pcs/h -1300 pcs/h Capacity

Egg Tray / Apple Tray / Egg Carton Making Machine 350pcs/h -1300 pcs/h Capacity

egg tray manufacturing machine

egg tray machine

Egg Carton Making Machine 350pcs/h

Place of Origin:

Jinan, Shandong, China

Brand Name:

Wanyou

Certification:

CE

Model Number:

ZSJ-1300

Contact Us
Request A Quote
Product Details
Voltage:
220V/380V/440V
Weight:
5 Tons - 45 Tons
Feature:
Automatic Type, Semi-automatic
Finished Products:
Egg Trays/Apple Trays, Shoe Trays Etc.
Drying Fuel:
Natural Gas, LPG, Coal Or Electricity
Raw Material:
Waste Newspaper, Cardboard Cartons, Any Waste Paper
Guarantee:
2years
Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
negotiation
Packaging Details
in container
Delivery Time
30 working days after get deposit payment
Payment Terms
T/T, L/C, Western Union, MoneyGram
Supply Ability
1 sets per month
Product Description



New Pulp Molding Egg Tray / Apple Tray / Egg Carton Machine Eco-friendly



Quick Detail



Condition:  New

Product Type: Egg Tray Machine

Processing Type: Pulp Molding Machine

Place of Origin: Shandong, China (Mainland)

Brand Name: RUNLIANG

Voltage: 220-440V

Power(W): 28kw~50kw

Dimension(L*W*H): 2300mm*1950mm*1600mm

Weight: 4 tons-20tons

Certification: CE & ISO

Warranty: 2 years

After-sales Service Provided:  Engineers available to service machinery overseas

Capacity: 350pcs/h -1300 pcs/h

Color: As  customer needs

Frequency:  50Hz-60Hz

Application:   egg tray,fruit tray,bottle tray

Workshop required:  50-180㎡

Worker required:  5-6 persons

Fuel:  Coal, Natural Gas, Disel, LPG and so on

Automation: Semi-auto and fully automatic

Keyword: Egg tray machine



Our machine is:



1. controlled by computer, no needs any basic construction.

​ 2. We could make all kinds of moulds for you, and it's very easy to change any moulds to the machine.

​ 3. England technology, and​ spare parts is very famous brand from Germany, Taiwan...

​ 4. with 2years warranty.

​ 5. The installation of the whole line is easy.





Technical data



Pulping Part HydraPulper 12kw - 35kw/h

Power:25KW,material of tank and disc:carbonized steel ,material of screen plate:stainless steel , pulping consistency:3-4%.



Mixer 7.5kw/h

Stainless steel shaft and impeller,Mixing diameter:1200mm,match with pulp chest of 2 meters deepth,match with pulp chest of 2 meters deepth. not included support bracket.



Disc Mill Pump 7.5KW It makes the waste paper into pulp, works continuously
Forming System 1 mold forming machine or 2 molds forming machine

 1 set

PLC control,stainless steel pulp tank,the surface of platens covered with stainless steel,the products should be transferred to a plate manually.The main electrical elements is Siemens brand.



Auto Drain System

Match with Forming System,include Air-water Seperation Tank,Auto Drain Tank,Support,Check Valve,Electromagnetic Valve, Inductor,etc



Control Cabinet for Forming System





The main electrical elements is China Famous brand.



Drying system 4-layer drying oven

Effective length 12m--24m, transfer speed adjustable. Fuel : Diesel oil/Nature gas/LPG



Control Cabinet for Drying System

380v/50hz

440v/60hz

220V/60HZ

Control the drying system.

Explosion-proof device







it can release the combustible gas remained in the drying line after ignition failures, preventing the explosion of drying line and protecting the worker and property.





Payment and delivery



Trade terms  FOB Qingdao or EXW Factory
Delivery time  About 25 working days after receiving the deposit.
Payment term  BY T/T 30%DEPOSIT+70%BALANCE.
Time of payment  When the deposit is paid, the machine will begin to be produced. And the balance should be paid by the consignee (the buyer) before the delivery.
Warranty time  Two years after the Egg tray machine received.
TERMS OF DELIVERY  FOB Qingdao Port, China
Package  In container
Certification  CE



Some world famous brands of the fittings:



1. the cylinder’s brand—FESTO

2. the electromagnetic valve’s brand—SHAKO

3. the pneumatic ball valve’s brand—SUPU

4. all the pump and motor are using famous brand of China.

5. the electric appliance’s brand—CHINT

6. the computer controller(PLC)--DELTA

7. the burner-- BALTUR/RIELLO



Our machine can provide customer 2 years warranty, which no other factory can supply.





Welcome to contact us.
