12-30 Cavity Small Egg Tray Fabricator With 45KW Total Power

12-30 Cavity Small Egg Tray Fabricator With 45KW Total Power

Small Egg Tray Fabricator

45KW Small Egg Tray Fabricator

30 Cavity small egg tray machine

Place of Origin:

Jinan, Shandong

Brand Name:

WANYOU

Model Number:

WY-1

Contact Us
Request A Quote
Product Details
Forming Type:
Reciprocating And Turnover Forming
Forming Molds Material:
Aluminum, Plastic, Copper, Customized
Machine Capacity:
700-1500pcs/h
Power Supply:
380V/50Hz
Machine Dimension:
7.5m*2.5m*2.2m
Operator:
2-3
Total Power:
45KW
Product Name:
Small Egg Tray Making Machine
Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
6500usd-18000usd
Packaging Details
plastic films
Delivery Time
depends
Payment Terms
TT
Supply Ability
1set/month
Product Description

Product Description:

One of the standout features of this egg tray maker is its powerful vacuum pump, which has a 7.5KW rating. This ensures that the forming molds are able to create perfectly shaped egg trays every time, resulting in a consistent and high-quality end product.

The forming molds of this small egg tray manufacturer are made from a range of materials, including aluminum, plastic, copper, and can even be customized to meet specific requirements. This level of flexibility allows users to choose the forming molds that best suit their needs and budget, ensuring that they are getting the most out of their investment.

The material used to create the egg trays is paper pulp, which is an eco-friendly and sustainable option that is both affordable and easy to source. The use of paper pulp also ensures that the egg trays are biodegradable and can be easily disposed of without harming the environment.

When it comes to drying the egg trays, this small egg tray manufacturer offers users a range of options to choose from. The trays can be sun-dried, which is a low-cost and traditional method that is suitable for small-scale operations. Alternatively, users can opt for a metal dryer or a brick kiln dryer, which are both more efficient and suitable for larger-scale operations.

In conclusion, the Small Egg Tray Making Machine is an excellent investment for small egg tray manufacturers who are looking for a reliable, efficient, and flexible way to produce high-quality egg trays. With its powerful vacuum pump, customizable forming molds, and range of drying options, this small egg tray constructor is sure to meet the needs of any small-scale egg tray manufacturing operation.

12-30 Cavity Small Egg Tray Fabricator With 45KW Total Power 012-30 Cavity Small Egg Tray Fabricator With 45KW Total Power 112-30 Cavity Small Egg Tray Fabricator With 45KW Total Power 212-30 Cavity Small Egg Tray Fabricator With 45KW Total Power 312-30 Cavity Small Egg Tray Fabricator With 45KW Total Power 412-30 Cavity Small Egg Tray Fabricator With 45KW Total Power 512-30 Cavity Small Egg Tray Fabricator With 45KW Total Power 612-30 Cavity Small Egg Tray Fabricator With 45KW Total Power 712-30 Cavity Small Egg Tray Fabricator With 45KW Total Power 8

Applications:

The WANYOU Small Egg Tray Making Machine is a highly efficient machine that can produce egg trays in bulk quantities. This machine is perfect for small egg tray fabricators, small egg tray builders, small egg tray factories, and other similar businesses. With its 7.5KW vacuum pump, 7.5KW driving motor, and 45KW total power, this machine can produce 12 to 30 egg trays per cavity.

The machine has a size of 7.5m*2.5m*2.2m, making it compact and easy to install in small spaces. The machine's supply ability is one set per month, making it an ideal choice for small egg tray fabricators and builders who are looking for a reliable and durable machine that can produce egg trays in large quantities. The WANYOU Small Egg Tray Making Machine is perfect for businesses that require a machine that can produce egg trays quickly and efficiently.

Overall, the WANYOU Small Egg Tray Making Machine is an excellent investment for small egg tray fabricators, small egg tray builders, and small egg tray factories. It is durable, efficient, and can produce egg trays in large quantities. If you are looking for a reliable machine that can help you produce egg trays for your business, the WANYOU Small Egg Tray Making Machine is an excellent choice.



Customization:

Egg Tray Mold Quantity 2pcs 3pcs 4pcs 12pcs(3pcs*4) 16pcs(4pcs*4) 24pcs(3pcs*8) 32pcs(4pcs*8)
Raw material Waste paper Waste paper Waste paper Waste paper Waste paper Waste paper Waste paper
Egg tray Capacity(pcs/hour) 700 1000 1300 2000 2500 3000 4000
Net weight per piece (gram) 70-75 70-75 70-75 70-75 70-75 70-75 70-75
Waste paper consumption 0.06ton / h 0.1ton / h 0.13ton / h 150kg/ h 150kg/h 188kg/h 225kg / hour
Water Consumption 0.15ton/h 0.22ton / h 0.3ton / h 0.45ton / h 0.6ton/h 0.68ton/h 0.9ton / h
Natural Gas Consumption of Dryer 25cbm/h 45cbm/h 60cbm/h 75cbm/h 90cbm/h 110cbm/h 120cbm/h
Boiler model (natural gas fuel Kcal) 300*103 450* 600*103 800*103 1000*103 1200*103 1500*103
Worker requirement 3-4workers 4-6workers 4-6workers 5-7workers 5-7workers 8-10workers 8-10workers
Power Requirement Without dryer 30KW 40KW 45KW 70KW 80KW 100KW 100KW
With dryer 45KW 60KW 65KW 100KW 120KW 130KW 150KW
Area of workshop Without dryer More than 100 M² More than 120 M² More than 150 M² More than
200 M²
More than 200 M² More than 250 M² More than 250 M²
With dryer More than 240M²
dryer-16M
More than300M²
Dryer-16M
More than 320 M²
dryer-18M
More than 400M²
Dryer18M
More than 400M²
Dryer20M
More than 520M² dryer30M More than 520M²
Dryer32M
Container Requirement Without dryer 20ft*1 40ft*1 40ft*1 40ft*1 40ft*1 40ft*1 40ft*1
With dryer 40ft*2+20ft*1 40ft*3 40ft*3 40ft*4 40ft*4 40ft*5 40ft*5
Remarks:
1. The Capacity calculated base on 30-packed egg tray(size 300x300mm, weight 70g~75g).
2. Workshop size is for reference only and could be adjusted according to actual size of client's plant.
3. The above specification is for reference only, due to continuous technology development, data will be updated from time to time.
4. Pulp Molding Equipment are non-standard equipment, we are able to provide customized solution according to specific requirements from customer.
5. Welcome to contact us anytime, our professional team will provide more effective help and supports for you.


Support and Services:

The Small Egg Tray Making Machine is a state-of-the-art product designed for small-scale egg tray production. It is easy to operate and maintain, and requires minimal technical expertise. The machine is made of high-quality materials, ensuring durability and long-lasting performance. Our technical support team is available to answer any questions you may have regarding the operation and maintenance of the machine. We also offer a range of services, including installation, training, and repair, to ensure that your machine operates at peak performance. Our goal is to provide our customers with the highest level of support and service to ensure their satisfaction with our product.



Packing and Shipping:

Product Packaging:

  • The small egg tray making machine will be packed in a wooden case to prevent damage during transportation.
  • The dimensions of the wooden case are 1100 x 1100 x 1600mm.
  • The weight of the wooden case is approximately 500kg.

Shipping:

  • The small egg tray making machine will be shipped by sea or by land, depending on the customer's location and preference.
  • The estimated shipping time is 15-30 days, depending on the destination.
  • The customer will be provided with a tracking number to monitor the status of the shipment.


FAQ:

Q: What is the brand name of the egg tray making machine?

A: The brand name of the egg tray making machine is WANYOU.

Q: What is the model number of the egg tray making machine?

A: The model number of the egg tray making machine is WY-1.

Q: Where is the egg tray making machine manufactured?

A: The egg tray making machine is manufactured in Jinan, Shandong.

Q: What is the minimum order quantity for the egg tray making machine?

A: The minimum order quantity for the egg tray making machine is 1 set.

Q: What is the price range of the egg tray making machine?

A: The price range of the egg tray making machine is 6500usd-18000usd.

Q: How is the egg tray making machine packaged for delivery?

A: The egg tray making machine is packaged with plastic films for delivery.

Q: What is the delivery time for the egg tray making machine?

A: The delivery time for the egg tray making machine depends on the location of the buyer.

Q: What are the payment terms for the egg tray making machine?

A: The payment terms for the egg tray making machine are TT.

Q: What is the supply ability of the egg tray making machine?

A: The supply ability of the egg tray making machine is 1 set per month.
