Customized Width Hydraulic Mill Roll Stand for Corrugated Paperboard Making

Customized Width Hydraulic Mill Roll Stand for Corrugated Paperboard Making

    • Customized Width Hydraulic Mill Roll Stand for Corrugated Paperboard Making
    • Customized Width Hydraulic Mill Roll Stand for Corrugated Paperboard Making
  • Customized Width Hydraulic Mill Roll Stand for Corrugated Paperboard Making

    Product Details:

    Place of Origin: Jinan, Shandong, China
    Brand Name: JUNLIANG
    Certification: CE
    Model Number: JL-P

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: As Discussion
    Packaging Details: in container
    Delivery Time: 35 working days
    Payment Terms: Western Union, MoneyGram, L/C, T/T
    Supply Ability: 1 set per month
    Contact Now
    Detailed Product Description
    Material: Cast Iron, Steel Driven Type: Electric
    Colors: Customized Appication: Paperboard Transferring
    Packaging: Plastic Film Voltage: 380V
    High Light:

    carton folding and gluing machine

    ,

    carton gluing machine



    Corrugated Paperboard Making Hydraulic Mill Roll Stand Different Width



    Corrugated Paperboard Making Hydraulic Mill Roll Stand Different Width



    It adopts symmetrical double roller with 4 arms structure.

    ※ Transmission pneumatic style to make cardboard clamping and lifting and correcting.

    ※ Top adopts expand chuck and to save paper. At the end of top adopts advanced film cylinder with pneumatic brake device or tension driving motor manually.

    ※ Support base paper width is 900mm-2550mm, support base paper diameter is 1500mm

    ※ Max. Supporting weight: 5 tons

    ※ You can choose heavy style full hydraulic shaft-less mill roll stand and the width of base paper is 2000mm-3000mm.

    ※ Max. Diameter of base paper: ¢1500mm

    ※ Adjusted pneumatically.



    Hydraulic system parameters:



    1, Work pressure(Mpa):16---18Mpa

    2, lifting hydraulic cylinder:100*440mm

    3. Clamping hydraulic cylinder:63*1300m

    4, hydraulic station motor power:5KW --380V -- 50Hz

    2, 5,solenoid valve voltage:220V 50 Hz

    Mainly purchased parts, raw materials and origin:



    Technical Data



    Paper stand action model hydraulic model
    clamp paper scrape

    max 1650mm , min 900mm



    clamp paper diameter max 1500mm
    single side max load paper weight

    2000kgs



    paper main shaft diameter

    219mm



    air compressor work pressure (Mpa)

    0.4-0.8mpa



    work power

    380v , 50hz
